Sterling Power Lithium Battery 12V 120Ah

Sterling Power Deep Cycle Lithium Battery 12V 120 Ah

The advantages of lithium batteries are well known over conventional batteries. They are superior on every level - everyone wants them.

However, installing them on vehicles was not simple and required a lot of knowledge because they have a very specific envelope for their charging and discharging curves. Failure to operate within these parameters will reduce the performance ability and life of the battery. It may even destroy the battery and even cause a fire. This fear has led to many people backing off from the whole idea of lithium batteries.

For many years people have wanted a simple easy solution to installing lithium batteries in the automotive industry: Including camper vans and caravans, however, due to the specific incompatibility with charging voltages and currents on board the vehicles and the requirements of the battery, the two things simply could not safely be brought together without a very elaborate intermediary system linked into a BMS for the lithium battery.

All this is not gone: today we have lithium batteries with built-in BMS and automatic shutdown systems that take care of the extreme faults that may be presented to a lithium battery. With the simple addition of a Battery to Battery charger, the correct voltage and current profile are provided to the battery from the vehicle's alternator with no integration fuss. This means, when your alternator voltage is low, the battery to battery charger increases the voltage and when your alternator's voltage is too high, the battery to battery charger decreases it. Also, when you have too much current, the battery to battery charger reduces the current, thus, presenting the lithium battery with its ideal safe voltage and current requirements.

The first, all in one - simple to install - package that removes all fears with this technology for application on vehicles

Features:

Built-in Battery Management System
Safety shut-down
Bluetooth battery monitoring app
less than half the weight of the equivalent lead-acid.
Can be put in series 12V | 24V | 36V | 48V
Fire-retardant plastic case

Specifications:

12V 120Ah LiFePO4 12V (nominal) 120Ah Lithium Deep cycle
Weight: 15kg
Dimensions (mm): 410L x 170W x 245H
Maximum continuous charge rate  = 50A
Maximum continuous discharge rate = 100A
Max Charge = 14.8V, Recommended Absorption Charge =14.6V, Recommended Float Charge V=13.8V
Cut off voltage 10V / cut off temperature 50 deg C
Charge Curve style  CC/CV
Operational temperature -30 Deg to 60 deg C (adjustable)
internal consumption: Operational = 10mA, Dormant 0.1mA
8mm ring terminal battery studs / washer
